Shot Blasting
Sandor CH-V
by Akyapak
Compact vertical chamber shot blasting machine with dual-side turbine arrays for efficient plate surface preparation in a space-saving footprint
Vertical chamber, dual-side blast
Machine type
Sandor CH 1.5 V, CH 2.5 V, CH 3 V
Models available
4 direct-drive, 30° angled
Blast turbines
Not sure if the Sandor CH-V is right for your application?
Our AI can help you compare machines, find parts, and explore your options.
Ideal For
- Steel fabrication shops and service centres that need consistent dual-side plate cleaning in a compact, space-efficient machine
- Operations processing a range of plate widths from 1,500 to 3,100 mm where vertical loading reduces manual handling and floor space
- Fabricators who demand automated operation with parts detection, variable-speed control, and hydraulic material handling to minimise labour costs
Machine type
Vertical chamber, dual-side blast
Models available
Sandor CH 1.5 V, CH 2.5 V, CH 3 V
Blast turbines
4 direct-drive, 30° angled
Turbine power
15–20 HP per turbine
Key Features
Sandor CH-V Features
Standard features that set this machine apart in demanding manufacturing environments.
Precision & Performance
- Automated variable-speed roller conveyor with frequency-inverter control lets operators fine-tune feed rate from 0.3 to 2.1 m/min for optimal surface finish
- Hydraulic transverse loader-unloader with heavy-duty lifting car and precision reducer streamlines material handling and reduces manual labour
Ease of Operation
- Labyrinth seal design on each turbine prevents abrasive leakage, maintaining blast efficiency and reducing maintenance
- Automatic parts-detection system opens the shot blast valve only when material enters the cabinet, eliminating wasted abrasive and energy
Safety & Reliability
- Four direct-drive turbines positioned at 30 degrees deliver aggressive, uniform blast coverage on both sides of the plate in a single pass
- Vertical plate orientation saves significant floor space compared to horizontal systems while allowing gravity-assisted abrasive recovery
- Three working widths — 1,500, 2,500, and 3,100 mm — cover a broad range of plate sizes from a single machine platform
Built-In Extras
- High-chrome steel impellers and manganese steel turbine housings with internal liners provide extended wear life under continuous production
- Double-wall blast cabinet with high-strength manganese steel surfaces and high-chrome cast liners in high-wear zones ensures long cabinet life
- Rubber curtains at entry and exit seal the cabinet, preventing abrasive escape and maintaining a clean shop floor environment
Video
See the Sandor CH-V in Action
Full Specifications
Akyapak Sandor CH-V Vertical Chamber Shot Blasting Machine Technical Details
Complete specifications, standard features, and optional upgrades.
- Machine type
- Vertical chamber, dual-side blast
- Models available
- Sandor CH 1.5 V, CH 2.5 V, CH 3 V
- Blast turbines
- 4 direct-drive, 30° angled
- Turbine power
- 15–20 HP per turbine
- Max work width
- 1,500–3,100 mm (59"–122")
- Max plate thickness
- 100 mm (4")
- Working speed
- 0.3–2.1 m/min (inverter-driven)
- Workpiece orientation
- Vertical plate processing
- Cabinet construction
- Double-wall steel with manganese liners
- Abrasive recovery
- Bucket elevator with curtain separator
- Dust collection
- Cartridge filter system
- Control system
- PLC with automatic parts detection
| Machine type | Vertical chamber, dual-side blast |
| Models available | Sandor CH 1.5 V, CH 2.5 V, CH 3 V |
| Blast turbines | 4 direct-drive, 30° angled |
| Turbine power | 15–20 HP per turbine |
| Max work width | 1,500–3,100 mm (59"–122") |
| Max plate thickness | 100 mm (4") |
| Working speed | 0.3–2.1 m/min (inverter-driven) |
| Workpiece orientation | Vertical plate processing |
| Cabinet construction | Double-wall steel with manganese liners |
| Abrasive recovery | Bucket elevator with curtain separator |
| Dust collection | Cartridge filter system |
| Control system | PLC with automatic parts detection |
- Four direct-drive turbines positioned at 30 degrees deliver aggressive, uniform blast coverage on both sides of the plate in a single pass
- High-chrome steel impellers and manganese steel turbine housings with internal liners provide extended wear life under continuous production
- Labyrinth seal design on each turbine prevents abrasive leakage, maintaining blast efficiency and reducing maintenance
- Automated variable-speed roller conveyor with frequency-inverter control lets operators fine-tune feed rate from 0.3 to 2.1 m/min for optimal surface finish
- Automatic parts-detection system opens the shot blast valve only when material enters the cabinet, eliminating wasted abrasive and energy
- Double-wall blast cabinet with high-strength manganese steel surfaces and high-chrome cast liners in high-wear zones ensures long cabinet life
- Rubber curtains at entry and exit seal the cabinet, preventing abrasive escape and maintaining a clean shop floor environment
- Hydraulic transverse loader-unloader with heavy-duty lifting car and precision reducer streamlines material handling and reduces manual labour
- Vertical plate orientation saves significant floor space compared to horizontal systems while allowing gravity-assisted abrasive recovery
- Three working widths — 1,500, 2,500, and 3,100 mm — cover a broad range of plate sizes from a single machine platform
- Extended conveyor lengths for longer plate workpieces
- Primer station integration for inline surface treatment after blasting
- Custom fixture configurations for non-standard plate and profile sizes
- Integration with downstream painting or coating systems
- Surface preparation of steel plate before painting, galvanising, or powder coating
- Mill scale and rust removal from plate stock in steel service centres
- Plate cleaning for shipbuilding, bridge construction, and pressure vessel manufacturing
- Pre-weld surface preparation to remove contaminants from joint areas
- Surface profiling to achieve specified anchor patterns for primer and coating adhesion
- Batch plate processing where consistent SA 2.5 or SA 3 finishes are required
