AC Machinery · Authorized dealer
Authorized Messer Cutting Systems dealer in Canada
Plasma, oxyfuel, fiber laser, and multi-process plate machinery, installed and serviced across Canada.
14
Models we supply
2007
Serving Canada since
Cambridge, ON
Parts and service
Messer plate machinery is the line we have supported the longest, and it is the deepest one we carry. Plasma, oxyfuel, fiber laser, drilling, tapping, and marking, on machines that run from a compact shop table up to a heavy gantry cutting 10 feet wide and 40 feet long.
What that range means in practice is that the decision is rarely about one machine. It is about which processes belong on one gantry and which are better kept apart. We have installed enough of these to have an opinion, and we will give it to you before you spend the money rather than after.
The lineup
Messer Cutting Systems machines we carry in Canada
Grouped by what they do. Every one of these is quoted, installed, and serviced by our own team.
Sheet & Plate Fiber Laser
See all Sheet & Plate Fiber Laser at ACM
Large-format fiber laser processing system
Element 400L - Large Format Shuttle
The Element 400L is the powerhouse of large format laser processing systems. With laser bevelling, inkjet marking, pinstamp marking, dual head laser cutting, and laser/plasma combination cutting, the Element 400L is the right choice for heavy cutting applications up to 10'x55'. Designed for fabricators needing a customizable, full-featured cutting platform with Global Connect CNC control.
- Max table size
- Up to 10'x55'
- Processes
- Laser cutting, laser bevelling, inkjet marking, pinstamp marking, dual head laser, laser/plasma combo
- Laser power
- Two fiber lasers up to 20 kW
- CNC control
- Global Connect
Fiber laser cutting system
FiberBlade - Compact Messer Laser
The Messer FiberBlade is an industrial fiber laser cutting system designed for high-speed, high-precision cutting of sheet and plate metal in production manufacturing environments. Available in flexible bed sizes from 5'x10' up to 8'x24' and with laser wattages up to 20kW.
- Bed sizes
- 3015 (5'x10'), 4020 (6.5'x13'), 6020 (6.5'x20'), 6025 (8'x20'), 6525 (8'x24')
- Laser power range
- 2 kW to 20 kW fiber laser
- Laser source
- IPG or MAX Photonics fiber laser
- Cutting head
- Precitec Procutter 2.0 (up to 20kW)
Plasma
See all Plasma at ACM
Durable unitized plasma/oxyfuel machine
EdgeMax
Durable unitized steel table/frame with optional plasma or oxyfuel capabilities and optional water table. Full capture bearing assemblies and low-mass aluminum beam powered by dual brushless AC motors. Rapid acceleration, precise motion, highly stable platform.
- Frame
- Unitized steel table/frame
- Beam
- Low-mass aluminum
- Motors
- Dual brushless AC
- Water table
- Optional
Large format gantry cutting system
Element 400G
The Element 400 Gantry features a rack-and-pinion drive system, large cutting areas, and customizable configurations. A versatile gantry platform for multi-process operations including plasma and oxyfuel cutting.
- Drive system
- Rack-and-pinion
- Cutting area
- Large format, customizable
- Cutting widths
- 6' to 16'
- Cutting lengths
- Up to 150'
High-productivity unitized plasma system
Element 400U
Developed with the ultimate in productivity and part quality in mind. True Industry 4.0 paperless factory connectivity. The Element 400 Unitized delivers exceptional speed, acceleration, and precision for high-volume plasma cutting operations.
- Top speed
- Up to 5,511 IPM
- Acceleration
- 1G
- Drive
- Helical rack and pinion (smooth, vibration-free)
- Rapid speed
- 2,600 IPM
Compact 5'x10' plasma and oxyfuel cutting machine
MetalMaster 3.0
Designed for manufacturers who need reliable plasma cutting without unnecessary complexity, the MetalMaster 3.0 delivers consistent cut quality, efficient material handling, and dependable day-to-day performance. Engineered by Messer Cutting Systems for precision plate processing, durability, and long-term productivity in demanding fabrication environments. Built for North American fabrication standards, the MetalMaster 3.0 is an ideal solution for shops requiring reliable plasma cutting in a compact format at a low cost. Machines are manufactured in North America and supported and serviced in Ontario, Canada.
- Cutting widths
- 5'
- Cutting lengths
- 10'
- Maximum material thickness
- Up to 6″ (process dependant)
- Plasma systems supported
- Hypertherm and equivalent industrial plasma systems
High-precision plasma cutting machine
MetalMaster Evolution
The MetalMaster Evolution is a high-speed, multi-process unitized plasma cutting system built for demanding fabrication environments. With cutting widths up to 10' and expandable lengths up to 50', it delivers +/-0.002" accuracy at positioning speeds up to 1,700 IPM. The standard Slagger® self-cleaning table eliminates manual slat maintenance, and the modular platform supports expansion into oxyfuel, drilling, bevelling, pipe cutting, and marking.
- Cutting widths
- 6' (1.8 m), 8' (2.4 m), and 10' (3 m)
- Cutting lengths
- 10' expandable in 5' increments up to 50' (15.24 m)
- Material thickness
- 26 gauge to 3"
- Materials
- Mild steel, stainless steel, aluminum
Cost-effective plate cutting system
Platemaster
The Platemaster offers a cost-effective solution for plate cutting. Robust, floor-mounted rails made from 90 lb/yd crane rail stock and sturdy end trucks for smooth dual box beam movement. Available in multiple machine widths and lengths for flexible plate processing.
- Rail
- Floor-mounted, 90 lb/yd crane rail stock
- Beam
- Dual box beam
- Plasma
- Up to 800 amps
- Oxyfuel
- Included
Heavy-duty gantry cutting machine
Titan III
The Titan III incorporates an innovative end truck configuration that effectively isolates electronics from the cutting area, ensuring robust performance in demanding environments. Built for heavy-duty operations where heat, dust, and sparks are constant factors.
- Key feature
- Electronics isolated from cutting area
- Design
- Innovative end truck configuration
- Cutting widths
- 6' to 16'
- Cutting lengths
- Up to 150'
Compact plasma and multi-process cutting system
Xcel Plasma
The Xcel Plasma delivers exceptional cutting precision and quality for plasma operations, coupled with rapid positioning and the highest acceleration capabilities. It minimizes unproductive intervals and features a built-in self-cleaning table. A versatile and compact plate processing platform designed for plasma cutting of material up to 2" thick with bed sizes from 6'x10' up to 10'x55'. Multiple process options including plasma, oxyfuel, and marking.
- Material thickness
- Up to 2" thick
- Table sizes
- 6'x10' up to 10'x55'
- Self-cleaning table
- Standard (built-in)
- CNC control
- Global Connect
CNC Drilling & Milling
See all CNC Drilling & Milling at ACM
Multi-tool plate processing gantry
Element 500
The Element 500 is Messer's multi-tool plate processing gantry, for structural steel shops that want drilled bolt holes and cut parts off the same machine. The GD40 drill head rides on the same reinforced beam as the plasma and oxyfuel tools, so a connection plate can be drilled, tapped, countersunk and cut in one setup instead of travelling between a cutting table and a drill line. The GD40 drills up to 1-9/16" through a Suhner CAT 40 spindle, with automatic tool changes and an optional 12-tool storage unit. A servo-controlled hold-down clamp keeps the plate steady while it drills, and air nozzles clear the chips before the next tool or torch goes to work. Cutting widths run from 6' to 16' and lengths up to 150', with room for up to six torch stations, including Bevel-S plasma bevelling and ALFA oxyfuel. AC Machinery supplies, installs and supports the Element 500 across Ontario and Eastern Canada.
- Cutting width
- 6' to 16'
- Cutting length
- Up to 150'
- Material thickness
- 26 ga. to 8" plate
- Drill head
- GD40, Suhner spindle with CAT 40 taper
Heavy-duty multi-process plate processing system
MPC2000
A heavy-duty workhorse plate processing system offering precision plasma, plasma beveling, oxyfuel, drilling (up to 2.5"), tapping, and markers, integrated on a single gantry. Ensures clean, precise cuts and holes with high accuracy. Featuring linear motion ways and reliable AC servo drives.
- Processes
- Precision plasma, plasma beveling, oxyfuel, drilling, tapping, markers
- Process heads
- 4
- Drilling capacity
- Up to 2.5" diameter
- Motion
- Linear motion ways
Versatile multi-process plate processing system with milling
MPC2000 MC
A versatile plate processing system offering up to five processes, including precision plasma, plasma beveling, oxyfuel, drilling (up to 2.5"), tapping, milling, and markers, integrated on a single gantry. Ensures clean, precise cuts and holes with high accuracy. Featuring linear motion ways and reliable AC servo drives. The MC variant adds milling capability and enhanced chip management.
- Processes
- Up to 5: precision plasma, plasma beveling, oxyfuel, drilling, tapping, milling, markers
- Process heads
- 4
- Drilling capacity
- Up to 2.5" (63.5mm) with chip breaking cycles
- Motion accuracy
- +/- 0.010" in 72" travel
Large-format plate processing system
TMC4500
Heavy-duty machine for larger and thicker plates with comprehensive automation options. Large-format plate processing with integrated drilling capability. Designed for high-volume operations requiring the most robust drilling and milling platform.
- Design
- Heavy-duty, large-format
- Plate capacity
- Larger and thicker plates
- Automation
- Comprehensive options available
- Cutting widths
- 12' to 28'
Why us
Why buy Messer Cutting Systems from AC Machinery
Multi-process experience
Plasma, oxyfuel, drilling, and marking on a single gantry only pays off if the configuration is right. We have specified and installed these across Canada and will tell you where the combination stops making sense.
Our own service team
Our technicians install the machine, train your operators, and come back when you need them. Emergency repair, preventive maintenance, and retrofits are all handled in house.
Parts stocked in Canada
We keep a stock of plasma consumables and spare parts in Canada, at our warehouse in Cambridge, Ontario, so a machine down on a Friday is not waiting on a border crossing.
Retrofits, not just new machines
An older Messer table is often worth upgrading rather than replacing. We retrofit controls and cutting technology on machines that still have good iron underneath.
FAQ
Messer Cutting Systems at AC Machinery: common questions
Answers to common questions about our messer cutting systems products.
Yes. We are an authorized dealer for Messer Cutting Systems in Canada, covering sales, installation, operator training, parts, and service.
We carry the Messer plate cutting range: plasma and oxyfuel gantries, multi-process machines that combine cutting with drilling and tapping, and fiber laser systems for sheet and plate. The current lineup is listed on this page.
Yes. We service Messer machines regardless of age or who supplied them, and we retrofit controls and cutting technology on older tables. Send us the model and serial number and we will tell you what is worth doing.
We keep a stock of consumables and spare parts in Canada, at our warehouse in Cambridge, Ontario. You can search our parts catalogue online, and anything not on the shelf we order directly.
Several of them can. Whether it should is the real question, because every process added to a gantry adds cost and complexity. We will walk through your part mix and tell you which processes earn their place.
Request a quote from this page or call us. Bring your plate sizes, thickness range, and typical volume, and we will come back with a configuration rather than a price list.
