AC Machinery · Authorized dealer
Authorized Han's Laser dealer in Canada
Sheet and plate lasers, tube lasers, and automation, quoted and supported from Cambridge, Ontario.
13
Models we supply
2007
Serving Canada since
Cambridge, ON
Parts and service
AC Machinery represents Han's Laser across Canada. We quote the machines, handle the installation, train your operators, and service them afterward with our own team. Parts are stocked here in Canada, so when a machine is down the part does not have to clear customs first.
Han's builds a wide range of fiber laser equipment, from compact sheet cutters through to large format plate systems, tube lasers, and automated loading, unloading, and storage. Our job is to work out which of those actually suits your material mix and your volume, and to quote only what we can stand behind afterward.
The lineup
Han's Laser machines we carry in Canada
Grouped by what they do. Every one of these is quoted, installed, and serviced by our own team.
Fiber Laser
See all Fiber Laser at ACM
Precise and flexible fiber laser cutting system with exchange table
J Series - Precise and Flexible
The J Series is an easy to use fiber laser cutting system featuring a double exchange workbench and gantry dual-drive structure. Available in multiple wattages and configurations the J Series has the flexibility to meet most any high production application. Its carbon steel welded bed with heat treatment delivers reliable dimensional accuracy, while the integrated cabinet design fits inside a single 40HQ shipping container for efficient delivery and installation.
- Model
- J Series
- Available laser power
- 2kW to 40kW
- Working area
- 3,100mm x 1,550mm (5'x10') up to 6,200mm x 2,600mm (8'x20')
- Max positioning speed
- 120 m/min
Fiber laser cutting system for Maximum performance
F Master - Maximum Performance
The F Master is the top of Han's enclosed fiber laser range and the machine we point at shops that want one platform to cover thin sheet through heavy plate. Six bed sizes run from 3,100 x 1,550 mm up to 12,200 x 2,550 mm, with laser power from 3kW to 60kW. A hollow-structure bed carries the full power range without thermal deformation, and an extruded aluminum gantry driven by the Han's 1201plus controller and Rexroth motors holds +/- 0.03 mm/m accuracy at 200 m/min positioning. The machine is fully enclosed behind OD6+ laser glass with an automatic rising and falling safety door.
- Models
- G3015F, G4020F, G6020F, G6025F, G8025F and G12025F
- Available laser power
- 3kW, 6kW, 12kW, 20kW, 30kW, 40kW, 60kW
- Working areas
- 3,100 x 1,550 mm (5'x10') up to 12,200 x 2,550 mm (40'x8')
- Max positioning speed
- 200 m/min
Compact and budget friendly fiber laser cutting machine
O PRO - Compact Value Laser
The O PRO is Han's single-platform enclosed fiber laser, and it is the one we recommend to shops that want a straightforward fully enclosed machine in a compact footprint. It comes in two bed sizes: the G3015-O PRO, which cuts a 3,100 x 1,550 mm sheet at up to 120 m/min, and the larger G4020-O PRO for shops that need a bigger table. Both run laser power from 3kW to 20kW. Sliding doors on the front and right sides open the table for loading, four laser-protected windows let the operator watch the cut without opening the machine, and control is through a handheld pendant and touchscreen running Han's 1201 bus-based CNC.
- Models
- G3015 and G4020
- Working area
- 3,100mm x 1,550mm (5'x10') or 4,100mm x 2,050mm (6'x12')
- Available laser power
- 3kW, 6kW, 12kW, 20kW
- Max positioning speed
- 120 m/min
Large format, high power gantry fiber laser cutting system
S PRO A/G - Large Format Gantry Laser
The S PRO-A/G is a large-format linear rail fiber laser cutting system built for heavy plate processing at 10kW and above. Available in cutting widths up to 4 metres and lengths up to 30 metres, it delivers stable thick-plate cutting with a modular bed design that simplifies shipping and installation. G-series models include an integrated bevel cutting head for weld preparation.
- Models
- G6025, G8025, G13025, G26025, G30025
- Available laser power
- 12kW, 20kW, 30kW, 40kW, 60kW
- Working area (width)
- 2,600 mm (options: 3 m, 3.5 m, 4 m)
- Working area (length)
- 6.1 m to 30.1 m (extendable)
Tube Laser
See all Tube Laser at ACM
High-speed fiber laser tube cutting system
F1 Tube Laser - High speed for small tube
The F1 is a high-speed fiber laser tube cutting system built for small-diameter round and square tube, angle iron, and channel steel from 10 to 120 mm. With traverse speeds to 150 m/min, 1.5 G acceleration, and fully automatic loading that changes material in seconds, it is engineered for high-volume small-tube production. Short-tail and zero-tail cutting keep scrap to a minimum, while a precision square-bore chuck and optional weld detection protect part quality. ACM stocks, installs, and supports the F1 across Canada from our Cambridge, Ontario facility.
- Tube range (round)
- 10-120 mm diameter
- Tube range (square)
- 10-120 mm
- Profile range
- Equal channel steel 5#-8#, equal angle steel 5#-8#
- Max traverse speed
- 150 m/min (Y-axis)
Small and medium tube fiber laser cutting system
PD Series - Up to 180mm (7") diameter
The PD Series is designed for efficient processing of small and medium-diameter tubes up to 180 mm. With laser power from 1kW to 4kW and modular feeding options from manual through fully automatic, it provides an accessible entry point for tube laser cutting with the precision and throughput needed for production environments.
- Models
- P6010D, P6018D, P8018D, P10018D
- Laser source power
- 1kW, 2kW, 3kW, 4kW (customisable)
- Max machining range
- 20-180 mm diameter (optional: 20-110 mm)
- Max rotational speed
- 120 rpm (optional: 150 rpm)
Professional fiber laser tube cutting system
PLT Series - High Speed and flexible
The PLT Series is a professional mid-range fiber laser tube cutting system for cutting carbon steel, stainless steel, copper, and aluminum alloy in square, round, oval, and special-shaped profiles. With modular configurations supporting 6, 9, or 12-metre tube lengths and optional semi-automatic or fully automatic feeding, it covers a wide range of tube processing requirements.
- Models
- PL2T-06, PL2T-09, PL3T-06, PL3T-09, PL3T-12
- Round tube diameter
- 20-240 mm (PL2T), 20-360 mm (PL3T)
- Square tube side length
- 20-240 mm (PL2T), 20-350 mm (PL3T)
- Max positioning speed
- 100 m/min (PL2T), 80 m/min (PL3T)
Heavy-duty fiber laser tube cutting system
TX Series - Heavy Duty Large Tube
The TX Series is a heavy-duty fiber laser tube cutting system for processing large-diameter carbon steel, stainless steel, and aluminum alloy pipes. With tube capacity up to 660 mm diameter and 2,500 kg load, it handles square, round, and oval profiles up to 12 metres long. Optional bevel cutting and tri/four-chuck configurations support complex structural and pipe fabrication.
- Models
- TX12036T, TX12050T, PX12066F
- Processing range (round)
- 40-360 mm (TX12036T), 50-500 mm (TX12050T), 80-660 mm (PX12066F)
- Processing range (square)
- 40-350 mm (TX12036T), 50-500 mm (TX12050T), 80-450 mm (PX12066F)
- Max speed
- 60 m/min (TX), 40 m/min (PX)
Automation
See all Automation at ACM
Fully automated sheet loading, cutting, and unloading system
ALU Series
The ALU Series handles every step between raw sheet and finished part without operator intervention. A servo-driven loading robot with independently controlled vacuum cups picks sheets from a multi-tower storage rack, places them on the cutting table, and an embrace-style fork unloader clears finished parts and scrap onto a double-layer sorting table below. Horizontal travel reaches 60 m/min with positioning accuracy inside one millimetre, so table exchange time stays short enough to keep the laser running continuously. ACM supplies ALU configurations from a single-tower, single-machine layout up to a four-machine line fed from dual storage columns with 10 to 40 rack positions. Every rack level holds up to three tonnes and the system measures weight and stack height automatically, triggering alerts before limits are reached. The integrated FMS scheduling platform assigns jobs with a single click, logs every cycle, and connects to existing MES and ERP systems. Two models cover the most common sheet formats: the ALU3015-B for sheets up to 3 m x 1.5 m, and the ALU4020-B for sheets up to 4 m x 2 m.
- Models
- ALU3015-B, ALU4020-B
- Max sheet size
- 3,000 x 1,500 x 20 mm (3015-B), 4,000 x 2,000 x 16 mm (4020-B)
- Horizontal travel speed
- Up to 60 m/min
- Lift speed
- Up to 9 m/min
Automated vertical sheet storage tower
AS Series
The AS Series replaces floor-level sheet racks with vertical tower storage that holds up to 60 tonnes of material in a fraction of the floor space. A single tower with 20 storage levels takes up roughly 4.5 x 4 metres of floor area while storing sheets, semi-finished parts, and finished workpieces on trays rated to three tonnes each. One-button tray retrieval completes in about 40 seconds, and the built-in warehouse management system tracks inventory in real time with barcode scanning and automatic weight and height measurement. ACM supplies the AS in two standard models: the AS3015-S for sheets up to 3 m x 1.5 m, and the AS4020-S for sheets up to 4 m x 2 m. Both offer 10, 15, or 20 storage levels with a maximum stacking height of 90 mm per level. The tower connects directly to laser cutting machines, press brakes, punch presses, and downstream equipment through a rear discharge port, making it the centrepiece of an automated production cell. Single, dual, or multi-tower configurations are available, and the WMS integrates with ERP and MES systems for centralized inventory control across the shop floor.
- Models
- AS3015-S, AS4020-S
- Max sheet size
- 3,000 x 1,500 mm (3015-S), 4,000 x 2,000 mm (4020-S)
- Storage levels
- 10, 15, or 20
- Load capacity per level
- 3 tonnes
Compact sheet automation system for laser cutting
CLU Series
The CLU Series uses a compact gantry structure to give a laser cutting machine continuous automated loading and unloading without the footprint of a full tower system. Independent loading and unloading modules work simultaneously: vacuum suction cups handle raw sheets while a separate fork mechanism clears finished parts, so the laser never waits for a table exchange. Sheet separation and thickness detection prevent double feeds and catch material errors before they reach the cutting head. ACM configures the CLU in two standard sheet formats (3015 for sheets up to 3,000 x 1,500 x 25 mm, and 4020 for sheets up to 4,000 x 2,000 x 16 mm). The modular construction means faster commissioning and simpler layout changes compared to fixed-frame systems. For shops moving toward unattended production, the CLU integrates with tower storage expansions and connects to MES platforms through its IoT-enabled control system. Safety guardrails and interlock switches come standard.
- Sheet formats
- 3015 (up to 3,000 x 1,500 x 25 mm), 4020 (up to 4,000 x 2,000 x 16 mm)
- Frame type
- Compact gantry structure
- Loading method
- Vacuum suction cups with sheet separation
- Unloading method
- Independent fork mechanism
Fully integrated sheet metal fabrication line
MLU Series
The MLU Series connects every stage of sheet metal fabrication into a single automated line. Intelligent storage towers feed raw sheets to gantry-structured laser cutting machines, vision-guided sorting stations classify finished parts by size or order, robotic press brakes handle bending to +/-0.01 mm tolerance, and laser welding stations complete the assembly with minimal thermal distortion. The entire sequence runs from a unified scheduling platform that coordinates material flow without manual intervention between stations. ACM configures MLU lines around each shop's specific product mix and throughput targets. The storage module uses compact vertical towers that take roughly one-fifth the floor space of conventional warehousing while handling over 100 tonnes of material daily. Vision-guided sorting uses industrial cameras with deep-learning algorithms for real-time part identification, and the robotic bending cells scan each part before picking for automatic alignment and forming. For shops producing energy storage cabinets, elevator panels, appliance housings, or general enclosures, the MLU eliminates the labour and handling time between separate cutting, bending, and welding stations.
- Process stages
- Storage, laser cutting, vision sorting, robotic bending, laser welding
- Daily material handling capacity
- Over 100 tonnes
- Bending tolerance
- +/- 0.01 mm
- Vision sorting
- Industrial cameras with deep-learning part identification
Automated sheet metal loading and unloading system
SLU Series
The SLU Series pairs a vacuum suction loading device with a comb-fork unloader on a single gantry-style C-frame, giving a laser cutting machine hands-free sheet exchange in a compact footprint. Individually controlled suction cups pick raw sheets with single-sheet detection to prevent double feeds, while the comb-fork mechanism slides under finished parts and scrap for clean removal. Two electronic carts rated at four tonnes each shuttle material between the storage area and the cutting station at 20 m/min. The welded C-frame goes through a stress-relief cycle (welding, rough machining, vibratory stress relief, precision finishing) for long-term dimensional stability. PLC-based control handles both manual and automatic modes, with modular programming that simplifies diagnostics and maintenance. ACM configures the SLU with optional FMS intelligent scheduling through the Hans APC-FMS 4.0 platform, which coordinates task assignment, parameter adjustment, and integration with ERP, MES, WMS, and CAM systems across the shop floor.
- Footprint (L x W x H)
- 18.5 x 5.6 x 4 m
- Max travel speed
- 40 m/min
- Max positioning speed
- 8 m/min
- Max sheet size
- 3,000 x 1,500 x 5 mm
Why us
Why buy Han's Laser from AC Machinery
A Canadian company
We are based in Cambridge, Ontario, and we have been selling and servicing steel processing equipment here since 2007. You are buying from a Canadian company, not a sales office.
Parts stocked in Canada
We hold spare parts in our own warehouse. When a machine goes down, the part ships from here rather than from overseas.
Our own service team
The same technicians who install your machine and train your operators are the ones who come back when you need them. Service is not subcontracted.
One Canadian source
Han's is one of several lines we represent. If a Han's machine is not the right answer for your work, we will say so and quote something that is.
Proven in production
Manufacturers running Han's Laser systems
Han's Laser is one of the largest laser system manufacturers in the world. These companies run Han's Laser equipment in their own plants, across laser cutting, marking and micro-processing. AC Machinery is an authorized Han's Laser dealer in Canada.
FAQ
Han's Laser at AC Machinery: common questions
Answers to common questions about our han's laser products.
Yes. We are an authorized dealer for Han's Laser in Canada. We quote the machines, install them, train your operators, and service them afterward with our own technicians.
We carry Han's sheet and plate fiber lasers, tube and profile lasers, and automated loading, unloading, and storage systems. The current lineup is listed on this page.
Yes. We service Han's machines whether or not we supplied them. Send us the model and serial number and we will tell you what we can cover.
We hold spare parts and consumables in our warehouse in Cambridge, Ontario. Anything not on the shelf we order directly, and we can tell you the lead time before you commit.
Our office and warehouse are in Cambridge, Ontario. Our service team travels to customers across Canada.
Request a quote from this page or call us. We will ask what you are cutting, your thickness range, and your volume before quoting, so the machine matches the work rather than the other way around.
